Genesis Blower Technical Information

The Genesis blower is well recognised in the whirlpool, bath and spa industry, due to its extensive range it is important to understand the features that the individual models provide:

Features

NN - Standard blower for electronic control/touchpad.
AN - Pneumatic air switch
Pneumatic on/off blower

HN - Heater
Standard blower for electronic control/touchpad with a built-in heating element to reduce cold air in the upstart.

AH - Pneumatic air switch & heater
Pneumatic on/off blower with built-in heating to reduce cold air in the upstart.

VN* - Variable speed
Standard blower including variable massage mode and automatic dry-out when using special touchpad UK01658A connected directly to the blower. No separate control panel is needed. See functional description under “VH”.

VH* - Variable speed & heater
Standard blower including variable massage mode and automatic dry-out when using special touchpad UK01658A connected directly to the blower. No separate control panel is needed. The blower has a built-in heating element to reduce cold air in the upstart. Functional description for the preset programme:

- Press the on/off button = high speed.
- Press the +/- button = in-/decrease blower speed.
- Press the ~ button = massage mode “pulsating effect”

Automatic stop: blower stops 30 min. after the user has operated one of the buttons for the last time.

Drying cycle: 30 min. after manual or auto switch off, the blower starts up at high speed for 2 secs. It then drops to low speed and increases gradually to high speed within 30 sec. The blower will then continue running for 4½ min. at high speed to drain the remaining water from the pipes.

ANT* - Pneumatic air switch & 3-speed
Pneumatic on/off blower including massage mode, automatic dry-out when using standard pneumatic air switch. See functional description under “AHT”.

AHT* - Pneumatic air switch, 3-speed & heater
Pneumatic on/off blower including massage mode, automatic dry-out when using standard pneumatic air switch. With built-in heating element to reduce cold air in upstart. Functional description for the preset programme:

1. Press the pneumatic button = high speed.
2. Press the pneumatic button = medium speed.
3. Press the pneumatic button = low speed.
4. Press the pneumatic button = massage mode “pulsating effect”.
5. Press the pneumatic button = off.

Automatic stop: blower stops 30 min. after the user has operated one of the buttons for the last time. Drying cycle: 30 min. after manual or auto switch off, the blower starts up at high speed for 2 secs. It then drops to low speed and increases gradually to high speed within 30 sec. The blower will then continue running for 4½ min. at high speed to drain the remaining water from the pipes.

* The preset programme can be changed via jumpers inside the blower to change the order of functions or to eliminate
the drying cycle. Request manual for detailed information.
